Faun ATF 60G-3
Pris eks. MVA
Ring for pris
3
Favoritt
Del
Lagre søkSkriv ut
INFORMASJON
Gruppe
Allterreng kraner
Merke / modell
Faun ATF 60G-3
Årsmodell
2019
Km.stand
41 270 km
Lagersted
Wildeshausen, Niedersachsen
Land
Tyskland
Mascus ID
9036D218
DETALJER
Lager nr.
ZG22670
Totalvekt
36 000 kg
Orginal farge
Gelb
Beskrivelse
WORLDWIDE SHIPPING AVAILABLE
Crane Chassis:3-axle chassis with sliding coupling at the front, 3 access steps on each side of the undercarriage, bracket for the 6t hook block on the right side of the boom rest, 4-point outriggers, hydraulic, with outrigger width detection, outrigger base widths: 6.40m / 5.40m / 4.40m / 2.40m, ZF AS-Tronic transmission mechanically linked to the engine, installed in the upper carriage, driving the undercarriage via angle gearbox and drive shafts, Drive through drive shafts from the upper carriage through the crane's slewing center, with differential and differential lock, 6x6x6 drive/steering – hydropneumatic suspension with level control, Dual-circuit compressed air brake system with ABS and air dryer, ZF Servocom dual-circuit hydro steering, mechanically and hydraulically assisted, all-wheel steering, crab steering, Two-person driver's cab with independent hot water heater Thermo 90 Pro, 24-volt electrical system with full lighting, including bi-halogen main headlights, LED daytime running lights, 2 LED fog lights, side marker lights, rear fog light, reversing lights, 4 support area floodlights switchable from the undercarriage cab, 2 rotating beacons, acoustic reverse alarm, centralized lubrication system
Crane Upper Carriage:
Torsion-resistant welded structure with an external-toothed, single-row slewing ring, Mercedes-Benz 6-cylinder diesel engine type OM 936 LA, EUROMOT IV, ZF AS-Tronic mechanical transmission, Dual-circuit hydraulic system, diesel-hydraulic, with oil cooler, 1 axial piston pump (electro-hydraulically adjustable) for telescoping, luffing, and hoisting gear, and 1 additional axial piston pump (electro-pneumatically adjustable) switchable for combined function telescoping, Two 4-way joystick controls, Five-section telescopic boom 9.5m–48.0m, telescopable under partial load, Luffing system with differential cylinder and integrated lowering brake valve, hoisting system with rope drum rotation sensor and end switch, hoist rope with SUPER-STOP rope lock, Slewing system with two-stage planetary gearbox, foot-operated service brake, and lock, Counterweight 5t, ballasting from the crane cab, Operating and control elements for crane operation and maneuvering from the crane cab, 24-volt electrical system with 2 work lights integrated into the upper carriage cab, Asymmetrical outrigger width detection with load moment limitation
Additional Equipment for Crane Chassis:
Tow coupling D-value 200kN 48 RF (not with 5.6), Eddy current brake on the 3rd axle, Tire pressure monitoring system, Aluminum toolbox at the rear with wooden storage compartment, Switchable reversing lights and mirrors, 10m jump-start cable, Tires: 14.00 R25, Reversing camera
Additional Equipment for Crane Upper Carriage:
1.6m heavy-duty jib, 25t load hook for installation in heavy-duty jib, Additional counterweight 7.9t for 13.0t maximum weight incl. LMB program for 3.3t / 7.2t / 8.0t / 9.2t / 10.1t / 13.0t counterweight, Wind speed sensor, 3-sheave hook block, double hook, 1-sheave hook block, single hook, Winch operating hours counter, Remote crane control, 2 work lights on base boom, Aviation warning light at boom head, Charging and jump-start socket, Monitoring camera for main winch
In the meantime, the crane has been labeled.
Offer without engagement. Without obligation or guarantee. Subject to prior sale. For a reservation is a deposit of 10% of the purchase price required. Until the money is not on our account, there is no reservation and not a claim on availability. The purchase is not concluded, until the full payment is received on our account. The vehicle shall remain our property until full payment. We only accept payments in Euro without additional cost to the seller and only by bank transfer. No checks. -
