Sany stc 1000

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Lifting Capacity Maximum rated lifting capacity: 100t Maximum rated lifting torque: 4320kN・m Maximum rated lifting torque at full extension of boom: 1800kN・m Minimum working radius: 3m Maximum lifting height - basic boom: 13.9m Maximum lifting height - fully extended boom: 60m Maximum lifting height - basic boom + jib: 78.1m Boom Dimensions Number of basic boom sections: 6 Boom length - basic boom: 13.25m Boom length - fully extended boom: 60m Boom length - basic boom + jib: 78.1m Jib installation angles: 0°, 15°, 30° Operating Speed Parameters Maximum lifting speed of main hoist: 135m/min Maximum lifting speed of auxiliary hoist: 135m/min Full extension time of boom: 420/400s Boom luffing time: 60/80s Slewing speed: 0～2.5r/min Engine Chassis engine model: Mercedes-Benz OM502LA Rated power of chassis engine: 375kW/rpm Upper engine model: U.S. Cummins QSB6.7 or Mercedes-Benz OM906LA.E2/5 Rated power of upper engine: 144kW/rpm or 150kW/rpm Driving Parameters Maximum driving speed: 85km/h Minimum turning radius: 11m Maximum climbing gradient: 45% Approach angle / departure angle: ≥21° Minimum ground clearance: 310mm Overall Specifications Overall length: 15396mm Overall width: 3000mm Overall height: 4000mm Operating weight: 54950kg Outrigger span: 7.6×7.6m
