Horyong BMK-403 ECO

Pris eks. MVA

Ring for pris

FavoriteFavoritt
shareDel
Save searchLagre søk
Skriv ut

INFORMASJON

Gruppe
Andre kraner
Merke / modell
Horyong BMK-403 ECO
Årsmodell
2018
Driftstimer
287 t
Lagersted
Duisburg, Nordrhein-Westfalen
Land
Tyskland
Generell tilstand
1
2
3
4
5
Mascus ID
A65059D6

DETALJER

Antall tidligere eiere
1
Totalvekt
4 019 kg
Maks løftekapasitet
4 200 kg
Maks løftekapasitet på Jib
3 000 kg
Lengde på bom
680 cm
Luffing jib
220 cm
Bomlengde på kran
680 cm
Løftehøyde
1 020 cm
Krokhøyde - horisontal bom
840 cm
Krokhøyde - skråstilt bom
221 cm
Motor overvogn
see chassis
Timer overvogn
200 t
Orginal farge
Silber-Grün
Motor undervogn
Electric
Transportmål (LxBxH)
435000 x 157000 x 205000 mm
Understell
Hjulvogn
Dekk merke
NM-Bereifung
Resterende fordekk
90
Resterende Bakdekk
90
Produsert i (land)
Sør Korea
Leveringsbetingelser
FCA, CPT, EXW
Sertifiseringer
CE, TÜV
Utstyr
Hakenflasche 1-rollig
Ektrautstyr
Krokblokker
Beskrivelse
Battery industrial yard crane HORYONG BMK-403 ECO, used unit battery drive, CE 2018, approx. 287 working hours Pick+carry and Carry deck TECHNICAL DETAILS: max. lifting capacity 4,2 t x 0,9 m max. load pick + carry 2,9 t max. load on carry deck 2,5 t max. working range 6,7 m (8,2 m with fly jib) max. hook height: 8,41 m (10,2 m with fly jib) DIMENSIONS & WEIGHT length 4.350 mm width 1.570 mm, height 2.050 mm total weight of crane: 4.019 kg outrigger base: 2.330 mm x 3.330 mm CRANE EQUIPMENT: telescopic main boom 3,07 bis 6,8 m, fully hydraulic, 3 sections fly jib with sheave head 2,2 m, max. lifting capacity 1,2 t, angel 0°, 25°, 50° one winch 360° slewing range unlimited Electronical Safe Load Indicator System Rayco Wylie i4500 working range limiter optical and voice warning system working light, emergency stop, round-about light hook block 1-sheave, max. 4,0 t lifting capacity drive 4 x 2 x 2 Carry-Deck for goods, size 1,55 m², max. load 2,9 t 3 pieces pipe holders / transport holders 4-point hydraulic outriggers, front and rear electric engine with batteries, 2x 10 kW, 72V / 300 Ah, rechargable batteries, integrated battery charger max. speed of crane is 6 km/h 4x non marking tires open crane driver cabin with lattice protection roof, operation panel The electric yard crane crane is in good working condition and can be ideally used inside hall areas where exhausts are vorbidden, The unit is immediately available ex our yard and can also be rented for jobsites in Germany.Vis mer
