CAT 320 B

All the auxiliary accessories can be provided for you. The above information is for reference only, and the specific details need to be confirmed with the factory.

The Caterpillar Cat320B excavator has various derivative models. The following are the common parameters of its basic model: ### General Specifications - **Operating weight of the whole machine**: 19,400 kg - **Standard bucket capacity**: 0.92 m³ - **Boom length**: 5,680 mm - **Stick length**: 2,900 mm - **Place of origin**: Japan - **Total transport length**: 9,440 mm - **Total transport width**: 2,800 mm - **Total transport height**: 2,940 mm - **Overall height of the cab**: 2,940 mm - **Minimum ground clearance**: 475 mm - **Tail swing radius**: 2,750 mm - **Track gauge**: 2,200 mm - **Track shoe width**: 600 mm - **Total track width**: 2,800 mm - **Track ground contact length**: 3,265 mm ### Power System - **Engine model**: Caterpillar CAT 3066T - **Rated power**: 99.9 kW / 1,800 rpm - **Bore × Stroke**: 102 mm × 130 mm - **Displacement**: 6.4 L ### Performance Parameters - **Slewing speed**: 10.7 rpm - **Travel speed**: 3.4 / 5.5 km/h - *
