Shantui SD16TF

Technical Features ● The winch installed on the rear end of the bulldozer can be used for transport of lumbers and other traction operations. For the operations in hazardous areas, the winch equipped can be used for self-rescue when necessary. Performance Parameters Length × width × height (mm) (excluding ripper) 5140×3388×3180 Operating weight(t) (excluding ripper) 17 Engine model SC11CB184G2B1 Net power/rated speed (kW/rpm) 120/1850 Ground pressure(Mpa) 0.058 Blade type Straight tilting blade Angle blade Blade capacity(m3) 4.5 for straight tilting blade 4.3 for angle blade Applicable Working Conditions Forest lumbering and road barrier clearance operations.
