Bobcat S 70
Pris eks. MVA
Skriv ut
INFORMASJON
Gruppe
Kompaktlastere
Merke / modell
Bobcat S 70
Årsmodell
2023
Driftstimer
550 t
Land
Kina
Generell tilstand
1
2
3
4
5
Mascus ID
CD627494
PRIS
Velg valuta
DETALJER
Lager nr.
1
Drivstoff
Diesel
Serie/VIN nummer
1
Sist godkjent (dato):
2025-06-27
Tilstand understell
Good Condition
Antall tidligere eiere
1
Totalvekt
1 268 kg
Maks løftekapasitet
686 kg
Reg. nr.
1
Karosseritype
Fastspent ramme
Førerhustype
Lukket hytte
Euroklasse
Steg V
Motor
Original
Volum skuff
0,10 m3
Effekt
16,8 kW (22,8 hk)
Motorprodusent
Original
Topphastighet
9,80 km/h
Ytelse hydraulikk
37 l/min
Transportmål (LxBxH)
2553 x 914 x 1814 mm
Orginal farge
Original
Understell
Hjulvogn
Tilstand Info/Garanti
1 Year
Dekk merke
Original
Resterende fordekk
98
Resterende Bakdekk
2
Dimensjon Bakdekk
Original
Dimensjon Fordekk
Original
Produsert i (land)
USA
Leveringsbetingelser
FCA, FOB, CIF, EXW
Sertifiseringer
EPA, CE
Utstyr
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Ektrautstyr
Klimaanlegg
Laste sensor
Ryggevarsler
Joystick
Beskrivelse
Basic performance parameters
Rated loading capacity: 343kg
Overturning load: 686kg
The total weight of the machine is 1268kg
Lifting mechanism form: Radial lifting
Rated loading bucket capacity: Not mentioned
Engine parameters
Engine model: Kubota KUbota D1005-E3B-BC-3
Rated power: 16.8kw/3000rpm
Maximum torque: 62.8N.m/2200rpm
Displacement: 1.001L
Number of cylinders: 3
Emission standard: Not mentioned
Through performance parameters
Drive motor form: Not mentioned
Maximum torque output by the drive motor: Not mentioned
Maximum driving speed: 9.8km/h
Tire size: 23×5.70-12
Front turning radius (with bucket) : 1557mm
Departure Angle: 25°
Hydraulic system parameters
Main pump type: Not mentioned
System safety pressure: 207bar
System rated flow rate: 37L/min
Ascension time: Not mentioned
Unloading time: Not mentioned
Release time: Not mentioned
Three items and: Not mentioned
Oil capacity parameters
Fuel tank: 24.6 liters
Hydraulic oil tank: Not mentioned
Hydraulic system: Not mentioned
Engine coolant: Not mentioned
Crankcase: Not mentioned
Sprocket oil tank: Not mentioned
Operation scope parameters
Maximum working height: Not mentioned
Maximum unloading height: 1891mm
Unloading distance (at the maximum height) : 469mm
The maximum height of the bucket hinge pin is 2399mm
The unloading Angle at the maximum unloading height: 34°
The retraction Angle of the bucket at its highest point: 97°
The retraction Angle of the bucket on the ground: 22°
Whole machine specification parameters
Total length (without attachments) : 1917mm
Total length (with bucket) : 2553mm
Full width (tire edge) : 901mm
Full width (edge of the bucket) : 914mm
Total height (up to the top of the cab) : 1814mm
Wheelbase: 722mm
Track: 752mm
Minimum ground clearance: 140mm
