Case SR 175
Pris eks. MVA
Skriv ut
INFORMASJON
Gruppe
Kompaktlastere
Merke / modell
Case SR 175
Årsmodell
2021
Driftstimer
1 060 t
Land
Kina
Generell tilstand
1
2
3
4
5
Mascus ID
CBD1AADC
PRIS
Velg valuta
DETALJER
Lager nr.
1
Drivstoff
Diesel
Serie/VIN nummer
1
Sist godkjent (dato):
2025-07-04
Tilstand understell
Good Condition
Antall tidligere eiere
1
Totalvekt
2 894 kg
Maks løftekapasitet
1 588 kg
Reg. nr.
1
Karosseritype
Fastspent ramme
Førerhustype
Lukket hytte
Euroklasse
Steg V
Motor
Original
Volum skuff
0,05 m3
Effekt
44,1 kW (60,0 hk)
Motorprodusent
Original
Topphastighet
18,4 km/h
Ytelse hydraulikk
72 l/min
Transportmål (LxBxH)
3400 x 1676 x 1970 mm
Orginal farge
Original
Understell
Hjulvogn
Tilstand Info/Garanti
1 Year
Dekk merke
Original
Resterende fordekk
98
Resterende Bakdekk
2
Dimensjon Bakdekk
Original
Dimensjon Fordekk
Original
Produsert i (land)
USA
Leveringsbetingelser
FCA, FOB, CIF, EXW
Sertifiseringer
EPA, CE
Utstyr
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Ektrautstyr
Tilleggshydraulikk
Laste sensor
Ryggevarsler
Joystick
Beskrivelse
Basic performance parameters
Rated loading capacity: 790kg
Overturning load: 1588kg
Overall weight: 2894kg
Lifting mechanism form: Radial lifting
Bucket lifting force: 31.8kN (or 31,800 N)
Boom lifting force: 21.3kN (or 21,300 N)
Engine parameters
Engine model: Cummins ISM N844T/M3
Working form: Non-direct injection
Rated power: 44.1kw/2900rpm (or 60hp, 1hp=0.7457kw, there is a difference in unit conversion here, but the values are similar and may vary due to different sources or versions)
Maximum torque: 171N·m/1800rpm
Displacement: 2.2L
Number of cylinders: 4 cylinders
Emission standard: EPA Tier3 (The third stage emission standard of the United States Environmental Protection Agency)
Through performance parameters
Maximum torque output by the drive motor: 1784N · m/cc (This parameter may vary depending on specific configuration)
Maximum driving speed: 11.8km/h (or 18.4km/h, optional)
Tire size: 10×16.5
Forward turning radius (with bucket) : 2000mm
Forward turning radius (without accessories) : 1300mm
Rear turning radius: 1600mm
Departure Angle: 22.5°
Parameters of the hydraulic system
Main pump type: Gear pump
System safety pressure: 210bar
System rated flow: 72L/min (or 108L/min, optional)
Oil capacity parameters
Fuel tank: 75.5L
Hydraulic system: 20L (This may refer to the capacity of a certain part of the hydraulic system. For specific details, please refer to the official instructions.)
Crankcase: 8.5L
Sprocket oil tank: 6.7L (Specific function and capacity may vary by model)
Operation range parameters
Maximum working height: (Not directly given, but can be calculated through other parameters)
Maximum unloading height: 2470mm
Unloading distance (at maximum height) : 540mm
The maximum height of the bucket hinge pin is 3100mm
The unloading Angle at the maximum unloading height: 39.6°
The retraction Angle of the bucket at its highest point: 98.6°
The retraction Angle of the bucket on the ground: 31.6°
Overall machine specification parameters
Total length (without accessories) : 2690mm
Total length (with bucket) : 3400mm
Full width (tire edge) : 1627mm
Full width (edge of the bucket) : 1676mm
Total height (up to the top of the cab) : 1970mm
Wheelbase: 1130mm
Track: 1350mm
Minimum ground clearance: 180mm
